Acteon X-Mind X-ray | AC & DC Intraoral Units

A cost-effective popular choice

Categories: Intraoral X-Ray, Intraoral X-Rays

  • satelec x-mind x-ray easily positions
  • The Satelec x-mind x-ray comes as a mobile solution
  • The Satelec x-mind x-ray comes as a mobile solution.
  • Acteon X-Mind X-Ray is conveniently offered in an AC and DC versions.
  • satelec x-mind x-ray with its easy to use display

The Acteon X-Mind X-ray come in an AC and DC model and is one of the most popular on the market from world-leading manufacturers, Acteon.

Simple and Reliable

Over the last 15 years the both AC and DC generators of the X-Mind have been the most sought after due to its solild and consistent performance.

Competitively Priced

Both models offers an affordable solution for dental surgeries.

Mobile Option

As an alternative the X-mind can be supplies with a mobile set up, for your conveniance.

Acteon is a world-leading MedTech company from France who use top of the range technology in all of their products to ensure both patients and dentists are more than satisfied.

Acteon are world leaders in the fields of dental imaging and specialist dental equipment.

The main difference between the X-mind AC and DC is that the DC overall has a better image quality with a lower dose rate.

Other design and manufacturing elements of this product include:

Smart Engineering

It’s “double chamber” light alloy heads are designed in one piece: the tube is in one chamber and the electronic components in another compartment in an oil bath (operating temperature regulation and high electrical insulation coefficient). The control software automatically compensates for variations in mains voltage, the radiation emitted is always of the best quality to provide pictures with reproducible parameters.

Smart Timer

The patented timer uses new technology which enables it to recognise automatically the type of generator and therefore to control an AC, with their specific command options (the X-Mind timer can be connected to two AC and/or DC generators at the same time).

Ease Of Use

The clearly organised commands make programming the X-rays easy thanks to the pictograms. The type of patient, the type of films or even special X-rays are easily managed. Exposure times can be customised and programmed.

Exposure Times

The X-Mind DC has an exposure time optimised for use with the latest generation conventional intra-oral X-ray films (type “F”), while being compatible with some digital sensors (from 0.02 to 3.2 sec. in 17 stages).

Using “F” type films reduces radiation by 60% compared with “D” type films.

Specifications for the Acteon X-Mind DC

Electromedical equipment, Class 1 type B

Supply voltage:

230~ - monophase 50/60Hz

Power absorption at 230V


Resistance of the line:


X-ray tube:

New Toshiba DG 073B DC tube

High Voltage


Anode current:


Focal spot:


Total filtration:

Equivalent to 2mm Al at 70kV

Tube inherent filtration:

Equivalent to 0.8mm Al at 70kV

Leakage radiation

Less than 0.25mGy/hour maximum at a distanceof 1m from focal spot

Long cone:

Focus to cylinder tip distance = 31cm (12”)


Exposure time can be set from 0.02 to 3.2 seconds

X-ray emission control:

“Dead man” switch with 3m spiral cable

Total weight:

25kg (weight of the head: 5.5kg)

Site survey: Recommended
